OMICRON 329
Accessories
22.4.2 Technical data
Table 22-24: EHB1 communication specifications
Characteristic Rating
Output
Number of channels 4
Devices per channel 1×CB MC2, 1×CB TN3 or 1×IOB1
Max. cable length 50 m/164 ft
Input
Number of channels 1
Interface
Communication
protocol
EtherCAT
®
Connector type RJ-45
Table 22-25: Power supply specifications
Characteristic Rating
Voltage
Nominal 100 V…240 V AC
Permitted 85 V…264 V AC
Current Maximal 2.5 A
Frequency
Nominal 50 Hz/60 Hz
Permitted 45 Hz…65 Hz
Connector type IEC320/C14, 1 phase
Table 22-26: Climate
Characteristic Rating
Temperature
Operating –10 ºC…+55 ºC/+14 ºF…+131 ºF
Storage –30 ºC…+70 ºC/–22 ºF…+158 ºF
Max. altitude
Operating 5 000 m/16 400 ft
Storage 12 000 m/40 000 ft
Table 22-27: Mechanical data
Characteristic Rating
Dimensions (w × h× d) 265 mm × 80 mm × 180 mm/10.4 inch × 3.1 inch × 7.1 inch
Weight 1.8 kg/4.0 lb
