3. Make sure that all cable connectors are clean and dry before being tightly connected.
Table 17-14: Hardware configuration options of CIBANO 500
CIBANO 500 Option
V IN (CAT III / 300 V)
1
External source, Trigger IN
1
or Disabled
1. Trigger signal starting the measurement
N Neutral connection of VIN
A-OUTPUT / INPUT (CAT III / 300 V)
A1
Main contact A, Close A, Motor A, Trigger IN
1
or Disabled
A2
Main contact B, Close B, Motor B, Trigger IN
1
or Disabled
A3
Main contact C, Close C, Motor C, Trigger IN
1
or Disabled
AN Common neutral connection for outputs/inputs in group A
B-OUTPUT / INPUT (CAT III / 300 V)
B1
Trip A, Trigger IN
1
, I clamp 1 or Disabled
B2
Trip B, Close, Trigger IN
1
, I clamp 2 or Disabled
B3
Trip C, Supply, Trigger IN
1
, I clamp 3, or Disabled
BN Neutral connection of outputs in group B
B4
Trigger IN
1
, I clamp 4, Motor or Disabled
C-INPUT (CAT III / 300 V)
C1 AUX 1
Dry contact
(potential-free)
Trigger IN
1
or Disabled
Wet contact
(with potential)
C2 AUX 2
Dry contact
(potential-free)
Trigger IN
1
or Disabled
Wet contact
(with potential)
C3 AUX 3
Dry contact
(potential-free)
Trigger IN
1
or Disabled
Wet contact
(with potential)
CN Neutral connection of inputs in group C
