OMICRON 17
Introduction
3.2.1 Front panel
Figure 3-1: Front view of CIBANO 500
WARNING
Death or severe injury caused by high voltage or current possible
Do not cover the status lights (for example, with a computer) since the status lights indicate
possible hazards.
Always observe the status lights while working with CIBANO 500.
Emergency Stop button
Press the button to immediately shut
off all current and voltage outputs.
See 3.2.4 "Emergency Stop button"
on page 20
Start/Stop button
Press the button to enable the
CIBANO 500 outputs and start a
measurement.
Press the button once more to stop
the measurement.
Status lights indicating possible hazardous
voltage and/or current levels at the
CIBANO 500 outputs
See Table 3-1: "Status lights" on page 20.
