Technical data
21 Technical data
21.1 Calibration interval of CIBANO 500
All input/output values are guaranteed for one year within an ambient temperature of 23 ºC ± 5 ºC/73 ºF
± 10 ºF, a warm-up time longer than 25 min. and in a frequency range of 45 Hz to 65 Hz. Accuracy
values indicate that the error is smaller than ±(value read × reading error [rd] + full scale of the range ×
full scale error [fs]). For mains voltages below 190 V AC the system is subject to power restrictions.
Technical data is subject to change without notice.
21.2 CIBANO 500 specifications
Table 21-1: General output specifications
Characteristic Rating
Frequency DC/15 Hz…400 Hz
Power
Vmains P
30 s
P
2h
>100 V 1500 W 1000 W
>190 V 3200 W 2400 W
Table 21-2: Voltage source (A & B)
Source Range I
max, 30 s
1
1. Within the power limits specified in Table 21-1: "General output specifications"
I
max, 2 h
1
DC high range 0…±300 V 27.5 A 12 A
DC low range 0…±150 V 55 A 24 A
AC high range 0…240 V 20 A 12 A
AC low range 0…120 V 40 A 24 A
Table 21-3: Current source (A & B)
Source Range V
max, 5 min
1
1. Within the power limit specified earlier in this section
V
max, 15 min
1
DC source 3 × 0…±50 A 50 V n/a
DC source 3 × 0…±24 A n/a 50 V
