CIBANO 500 PTM User Manual
320 OMICRON
22.2.2 Technical data
Table 22-8: CB TN3 specifications
Characteristic Rating
Max. number of
digital/analog
transducers used
simultaneously
3
Interface to CIBANO 500
Communication
protocol
EtherCAT
®
Connector type RJ-45
Table 22-9: Analog transducer interface
Characteristic Rating
Output
Number of channels 3
Voltage 5 V…30 V DC
Current 10 mA…50 mA
Voltage input
Number of channels 3
Range 30 V
Accuracy
1
1. Means “typical accuracy”; 98% of all units have an accuracy which is better than specified.
0.1% rd + 20 mV
Maximum sample rate 40 kHz
Minimum resolution 25 μs
Current input
Number of channels 3
Range 50 mA
Accuracy
1
0.1% rd + 20 μA
