Omicron CIBANO 500 PTM - Setting the Geo Coordinates; Managing Attachments

OMICRON 59
Create new guided jobs
7.3.2 Setting the geo coordinates
To set the geo coordinates of a location:
1. In the location view, click Edit coordinates.
Figure 7-6: Edit Coordinates dialog box
2. In the Edit Coordinates dialog box, enter the latitude and longitude of the location by using the
WGS-84 World Geodetic System in the DMS (degrees, minutes, seconds) format.
7.3.3 Managing attachments
Under Attachments, you can manage attachments to locations.
► To add an attachment to a location, click the Add button , and then browse to the file you want to
attach to the location.
► To open an attachment, select the attachment, and then click the Open button , or double click
the attachment.
► To remove an attachment from a location, select the attachment you want to delete, and then click
the Remove button .
