CIBANO 500 PTM User Manual
314 OMICRON
22.1.2 Technical data
Table 22-1: CB MC2 specifications
Characteristic Rating
Current output
Number of channels 2
Current source 0…100 A DC
Maximum output
voltage
2.6 V DC
Static contact resistance measurement
Range 0.1 μΩ…1000 μΩ
Accuracy
1
1. Means “typical accuracy”; 98% of all units have an accuracy which is better than specified.
0.2% rd + 0.1 μΩ
Measuring current 100 A
Dynamic contact resistance measurement
2
2. Valid for test currents 10 A
Range 10 μΩ…200 mΩ
Accuracy
1
0.2% rd + 10 μΩ
Settling time 40 μs
Maximum sample rate 40 kHz
Minimum resolution 25 μs
Pre-insertion resistance (PIR) measurement
Range 0…10 kΩ
Accuracy (<500 Ω)
1
0.5% rd + 10 mΩ
Accuracy
(500 Ω…10 kΩ)
1
3% rd
Timing measurement
Maximum sample rate 40 kHz
Minimum resolution 25 μs
Accuracy ±1 sample interval ±0.01% rd
Interface
Communication
protocol
EtherCAT
®
Connector type RJ-45
