OMICRON 315
Accessories
All input/output values are guaranteed for one year within the environmental conditions specified in the
following table.
Table 22-2: Maximum output current duration with a fully charged capacitor
1
1. Only valid if the standard 3 m red and 0.75 m black high-current cables are used.
Output current
Load
100 μΩ 500 μΩ 3mΩ
1 × 100 A 6200 ms 5960 ms 4460 ms
2 × 100 A 1900 ms 1780 ms 1030 ms
Table 22-3: Climate
Characteristic Rating
Temperature
Operating –30 ºC…+70 ºC/–22 ºF…+158 ºF
Storage –30 ºC…+70 ºC/–22 ºF…+158 ºF
Max. altitude
Operating 5 000 m/16 400 ft
Storage 12 000 m/40 000 ft
Table 22-4: Mechanical data
Characteristic Rating
Dimensions (w × h× d) 109 mm × 272 mm × 63 mm/
4.3 inch × 10.7 inch × 2.5 inch
Weight 1.2 kg/2.6 lb
