Omicron CIBANO 500 PTM - Technical Data

OMICRON 325
Accessories
22.3.2 Technical data
Table 22-15: Voltage measurement on BINARY OUT/BINARY IN (CAT III / 300 V)
1
1. For limited specifications, see Table 22-21: "Climate" on page 326.
Signal type Measurement range Accuracy
2
2. Means “typical accuracy”; 98% of all units have an accuracy which is better than specified.
DC, continuous
300 V
0.05% rd + 0.05% fs
AC, continuous 0.05% rd + 0.02% fs
Table 22-16: Current measurement on BINARY OUT (CAT III / 300 V)
1
1. For limited specifications, see Table 22-21: "Climate" on page 326.
Signal type Measurement range Accuracy
2
2. Means “typical accuracy”; 98% of all units have an accuracy which is better than specified.
DC, continuous
40 A
0.1% rd + 0.2% fs
AC, continuous 0.1% rd + 0.05% fs
Table 22-17: Voltage rating on BINARY OUT/BINARY IN (CAT III / 300 V)
1
1. For limited specifications, see Table 22-21: "Climate" on page 326.
Voltage per channel Duty cycle
±300 V DC or AC continuous
±500 V transient peak
Table 22-18: Current rating on BINARY OUT (CAT III / 300 V)
1
1. For limited specifications, see Table 22-21: "Climate" on page 326.
Current per channel Duty cycle
24 A
RMS
DC or AC
continuous
40 A
RMS
AC or 55 A
peak
200ms on, 5s off
±85 A transient peak
Table 22-19: Timing accuracy
Characteristic Rating
Timing accuracy ±1 sample interval ±0.01% rd
