CIBANO 500 PTM User Manual
326 OMICRON
All input/output values are guaranteed for one year within the environmental conditions specified in the
following table.
Table 22-20: BINARY IN (CAT III / 300 V)
1
1. For limited specifications, see Table 22-21: "Climate" on page 326.
Characteristic Rating
Binary input type
Toggling with potential-free (dry) contacts or voltages
(wet)
up to 300 V DC
Maximum sample rate 40 kHz
Minimum resolution 25 μs
Table 22-21: Climate
Characteristic Rating
Temperature
Operating –10 ºC…+55 ºC/+14 ºF…+131 ºF
Storage –30 ºC…+70 ºC/–22 ºF…+158 ºF
Max. altitude
Operating
2000 m/6550 ft, up to 5000 m/16400 ft with limited
specifications
1
1. BINARY OUT (CAT III / 300 V) outputs and BINARY IN (CAT III / 300 V) inputs: from 2000 m/6550 ft to 5000 m/16400 ft
altitude only CAT II compliance or CAT III compliance with half voltage
Storage 12 000 m/40 000 ft
Table 22-22: Mechanical data
Characteristic Rating
Dimensions (w × h× d) 381 mm × 190 mm × 90 mm/15 inch × 7.5 inch × 3.5 inch
Weight 3.0 kg/6.6 lb
