CIBANO 500 PTM User Manual
304 OMICRON
21.3 Interfaces
CIBANO 500 provides the following interfaces.
Table 21-9: Voltage input VIN (CATIII/300V)
1
1. For limited specifications, see Table 21-19: "Climate" on page 310.
Input Range Accuracy
2
2. Means “typical accuracy”; 98% of all units have an accuracy which is better than specified.
DC input 0…420 V 0.5% rd + 0.5% fs
AC input 0…300 V 0.5% rd + 0.5% fs
Table 21-10: Binary input A (CAT III / 300 V)
1
1. For limited specifications, see Table 21-19: "Climate" on page 310.
Characteristic Rating
Binary input type
Toggling with potential-free (dry) contacts or voltages (wet)
up to 300 V DC
Maximum sample rate 40 kHz
Minimum resolution 25 μs
Table 21-11: Interfaces
Interface Rating
Digital 2 × safety connection dongle, 1 × serial, 1 × Ethernet
EtherCAT
®
module: 4 × EtherCAT
®
Auxiliary module: 1 × EtherCAT
®
, 3 × binary input (C)
Analog 1 × analog input (V IN)
3 × analog input/analog output/binary input (A)
4 × analog input/analog output (B)
Auxiliary module: 3 × binary input (C)
