CIBANO 500 PTM User Manual
306 OMICRON
21.3.3 Auxiliary module
21.4 SAFETY connectors
CIBANO 500 has two SAFETY connectors: SAFETY 1 (primary) and SAFETY 2 (secondary) for
connecting optional OMICRON safety accessories (for more information, see the Safety Accessory
Supplementary Sheet provided by OMICRON). Both connectors have as default a removable safety
connector dongle connected to it. Removing either one or both safety connector dongles will open the
emergency stop circuit loop inside CIBANO 500 preventing the operation of the device.
21.4.1 Using the safety accessories
OMICRON offers several safety accessories designed to enhance the safety awareness and/or safety
when using CIBANO 500. The use of a safety accessory typically requires the removal of one of the
safety connector dongles to allow the safety accessory to be plugged in. Some safety accessories
themselves contain a SAFETY OUT connector to allow daisy-chaining safety accessories with each
other. If the connected (or the last daisy-chained) safety accessory itself also contains a SAFETY OUT
connector, the safety connector dongle initially removed from CIBANO 500 SAFETY 1 or SAFETY 2
connector must be attached to it to close the emergency stop loop.
Table 21-14: Voltage input C (CATIII/300V)
1
1. For limited specifications, see Table 21-19: "Climate" on page 310.
Input Range Accuracy
2
2. Means “typical accuracy”; 98% of all units have an accuracy which is better than specified.
DC input 0…420 V 0.5% rd + 0.1% fs
AC input 0…300 V 0.5% rd + 0.1% fs
Table 21-15: Binary input C (CAT III / 300 V)
1
1. For limited specifications, see Table 21-19: "Climate" on page 310.
Characteristic Rating
Binary input type
Toggling with potential-free (dry) contacts or voltages (wet)
up to 300 V DC
Maximum sample rate 40 kHz
Minimum resolution 25 μs
Table 21-16: Interfaces
Interface Rating
Digital
1 × EtherCAT
®
Analog 3 × binary input
