OMICRON 133
Off-service diagnostic methods
Contact bounce filter
Main contact Threshold value of the time interval between two consecutive bounces of
the main contact. For time intervals equal or below the threshold, the
contact is considered as closed.
Setting the value to 0.0 ms deactivates the contact bounce filter.
Auxiliary contact Threshold value of the time interval between two consecutive bounces of
the auxiliary contact. For time intervals equal or below the threshold, the
contact is considered as closed.
Setting the value to 0.0 ms deactivates the contact bounce filter.
Average coil current/voltage
Begin Start of the average coil current/voltage evaluation in percent of the time
period during which the current flows through the coil
End End of the average coil current/voltage evaluation in percent of the time
period during which the current flows through the coil
Sequence
See Table 17-9: "Timing test sequences" on page 134.
1. The Close breaker before test check box is only active if the test sequence begins with the open command and no output is
set to Trigger IN.
Table 17-8: Advanced settings of the Timing test (continued)
Setting Description
