CIBANO 500 PTM User Manual
156 OMICRON
2. Optionally, enter the advanced settings in the Advanced settings area.
3. In the Assessment area, configure the assessment.
► Click Edit configuration or click in one of the tables to open the Assessment configuration
dialog box, and then edit the assessment limits.
► Select the Automatic assessment check box to enable the automatic assessment.
Note: For the assessment limit definitions, see 15.3 "Assessment limits" on page 107.
4. In the Measurements area, click Start.
The blue ring on the Start/Stop button is on.
5. Start the measurement by pressing the Start/Stop button.
The blue ring on the Start/Stop button flashes for approx. 3 seconds, and the lightning symbol in
Primary Test Manager and the red status light on the front panel are flashing.
Note: In emergency cases, you can abort the measurement anytime manually by pressing the
Emergency Stop button on the CIBANO 500 front panel.
6. After the charging process has finished, CIBANO 500 stops the measurement automatically.
The lightning symbol in Primary Test Manager stops flashing, the green status light is on, and Primary
Test Manager displays the measurement results.
4. Only available if Control board is selected as supply source.
5. Only available if at least one output in group B is set to I clamp x.
6. Only available if VIN, or one output in group A or group B is set to Trigger IN.
Table 17-28: Advanced settings of the Motor Current test
Setting Description
Other
Sample rate Measurement sample rate
Charging current
Begin Start of the charging current evaluation in percent of the total charging
duration of the motor
End End of the charging current evaluation in percent of the total charging
duration of the motor
WARNING
Death or severe injury caused by high voltage or current possible
► Do not enter the high-voltage test area while testing with CIBANO 500 since any part of the
circuit breaker can carry dangerous voltages.
► Stay in the work area during the test.
