CIBANO 500 PTM User Manual
160 OMICRON
Table 17-31: Insulation Resistance measurement data
Setting Description
Test data To import a file containing test data:
► Click Add to browse your computer and add data from a file.
To directly import data from a measurement file:
► Open the file on your computer.
► In the file press CTRL+A to mark all content, and then press CTRL+C
to copy.
► In Primary Test Manager press Paste from clipboard.
The results may take a few seconds to load.
Measurement Name or number of the measurement
PI Polarization index
DAR Dielectric absorption ratio
Time Time at which the given values were recorded
Voltage
Voltage and current values recorded at the Time specified in the first
column
VDC
IDC
