CIBANO 500 PTM User Manual
162 OMICRON
2. In the Supply settings dialog box, enter the supply voltage you want to use for testing your circuit
breaker.
► To activate the continuous power supply, click ON in the status bar. After you click Activate in the
Activate power supply dialog box, the configured supply voltage is applied to the B3 socket, and
the red light on the front panel will be flashing indicating possibly dangerous operating condition.
Note: If you have activated the continuous power supply, the coil supply settings are not available
because the supply voltage is set by the continuous power supply.
► To deactivate the continuous power supply, click OFF in the status bar.
WARNING
Death or severe injury caused by high voltage or current possible
► Do not touch the B3 socket and any connected cables after you have activated the continuous
power supply.
► Always use a strobe light to warn the operating personnel of the possibly dangerous operating
condition.
CAUTION
Personal injury due to unexpected operation of the circuit breaker possible
► Before deactivating the continuous power supply, open the circuit breaker.
