Off-service diagnostic methods
2. Make sure that all cable connectors are clean and dry before being tightly connected.
Table 17-84: Hardware configuration options of CIBANO 500
CIBANO 500 Option
A-OUTPUT / INPUT (CAT III / 300 V)
A1 Current +
A2 Current +
A3 Current +
AN Not connected in this test
B-OUTPUT / INPUT (CAT III / 300 V)
B1 Current –
B2 Current –
B3 Current –
BN Voltage Sense –
B4 Voltage Sense +
