Common Specifications for General-purpose Slaves Section 5-1
5-1 Common Specifications for General-purpose Slaves
The following table lists specifications which are common to all General-pur-
pose Slaves. For details of specifications for each Slave, refer to the following
Slave specifications pages.
Note Some items for the DRT2-ROS16 (Remote I/O Terminal with relay outputs)
have different specifications. Refer to 5-5-8 Remote I/O Terminal with 16
Relay Outputs: DRT2-ROS16.
5-1-1 Current Consumption and Weights
The following table lists the current consumption and weights for general-pur-
pose Slaves.
Item Specifications
Communications power
supply voltage
11 to 25 V DC
(Supplied from the communications connector.)
I/O power supply voltage 20.4 to 26.4 V DC (24 V DC, −15 to +10%)
Noise immunity Conforms to IEC61000-4-4. 2 kV (power lines)
Vibration resistance 10 to 60 Hz, 0.7-mm double amplitude
60 to 150 Hz, 50 m/s
2
For 80 min. in each direction
Shock resistance
150 m/s
2
, 3 times in each direction
Dielectric strength 500 V AC (between isolated circuits)
Insulation resistance 20 MΩ min. at 250 V DC (between isolated circuits)
Ambient temperature −10 to +55°C
Ambient humidity 25% to 85% (with no condensation)
Operating environment No corrosive gases
Storage temperature −25 to +65°C
Mounting 35-mm DIN Track mounting or M4 screw mounting
Mounting strength 50 N
Track direction: 10 N
Screw tightening torque M2 (communications connector lock screws): 0.26 to
0.3 N·m
M3 wiring screws: 0.5 N·m
M3 mounting screws: 0.5 N·m
M4 (Unit mounting screws): 0.6 to 0.98 N·m
Model Communications current
consumption
Weight
DRT2-ID08 55 mA max. 135 g max.
DRT2-ID08-1 55 mA max. 135 g max.
DRT2-OD08 50 mA max. 135 g max.
DRT2-OD08-1 45 mA max. 135 g max.
DRT2-MD16 55 mA max. 145 g max.
DRT2-MD16-1 50 mA max. 145 g max.
DRT2-ID16 60 mA max. 140 g max.
DRT2-ID16-1 60 mA max. 140 g max.
DRT2-OD16 60 mA max. 140 g max.
DRT2-OD16-1 60 mA max. 140 g max.
DRT2-ROS16 395 mA max. 260 g max.
XWT-ID08 (See note.) 5 mA max. 80 g max.
XWT-ID08-1 (See note.) 5 mA max. 80 g max.
