272
Standard Environment-resistive Terminals Section 6-5
6-5-5 Environment-resistive Terminals with 4 Transistor Outputs (IP67):
DRT2-OD04CL (NPN) and DRT2-OD04CL-1 (PNP)
Output Specifications
Indicators
I/O Status Indicators The I/O status indicator displays and their meanings are shown in the follow-
ing table. Refer to the section following on names of components and func-
tions for details on the location of the I/O status indicators. In the indicator
name “1-A,” the “1” indicates the connector number, and the “A” indicates that
it is an I/O status indicator.
Note Although the connectors are numbered from 1 to 4, the input bits are num-
bered from 0 to 3.
I/O Power Supply Status
Indicator
Item Specifications
Model DRT2-OD04CL DRT2-OD04CL-1
Internal I/O common NPN PNP
Output points 4 points
Rated output current 0.5 A/point, 2.0 A/common
I/O power supply
voltage
20.4 to 26.4 V DC (24 V DC, −15 to +10%)
Residual voltage 1.2 V max. (0.5 A DC,
between each output terminal
and G)
1.2 V max. (0.5 A DC,
between each output terminal
and V)
Leakage current 0.1 mA max.
ON delay time 0.5 ms max.
OFF delay time 1.5 ms max.
Number of circuits 4 points with one common
Indicator Color Status Meaning
1-A Yellow ON Output 0 is ON.
2-A Yellow ON Output 1 is ON.
3-A Yellow ON Output 2 is ON.
4-A Yellow ON Output 3 is ON.
Indicator Color Status Meaning
AUX PWR Green ON I/O power is being supplied.
