Omron DRT2 SERIES DEVICENET SLAVES - OPERATION MANUAL 04-2008 User Manual

104
Remote I/O Terminals with Transistors Section 5-5
DRT2-ID08-1 (PNP)
Note Wire colors in parentheses are the previous JIS colors for photoelectric and
proximity sensors.
Dimensions: DRT2-ID08 and DRT2-ID08-1
5-5-4 Remote I/O Terminals with 8 Transistor Outputs: DRT2-OD08
(NPN) and DRT2-OD08-1 (PNP)
Output Specifications
V
10
1
11
3
12
5
13
7
14
NC
15
G
1
0
2
2
3
4
4
6
5 6
24 V DC
+-
16 17 18
7 8 9
NC
NC
NC
NC
NC
NC
NC
I/O power
supply
3-wire sensor with
PNP output
(photoelectric or
p
roximit
y
sensor
)
2-wire sensor
(e.g., limit switch)
Blue (black) Black (white) Brown (red) Blue (black) Brown (white)
43.8
115
3.1
50
49.6
29.8
Item Specifications
Model DRT2-OD08 DRT2-OD08-1
Internal I/O common NPN PNP
Output points 8 points
Rated output current 0.5 A/point, 4.0 A/common
Residual voltage 1.2 V max.
(at 0.5 A between each output
terminal and G)
1.2 V max.
(at 0.5 A between each output
terminal and V)
Leakage current 0.1 mA max.
ON delay time 0.5 ms max.
