203
Screw-less Clamp Terminals Section 5-7
5-7 Screw-less Clamp Terminals
The Screw-less Clamp Terminal has a structure designed for clamping to a
terminal block. It is a reduced-wiring, labor-saving Slave that can make wiring
easy by simply inserting post terminals (sleeves). The Unit and terminal block
can be detached, making it possible to replace the Unit in the event of a failure
without removing the wiring.
There are two categories of Screw-less Clamp Terminals: Those that have
detection functions for early detection of errors, and those that do not.
Models without Detection Functions
Models With Detection Functions
5-7-1 Node Address, Baud Rate, and Output Hold/Clear Settings
These settings are made in the same way as for Remote I/O Terminals (Tran-
sistor Type). Refer to 5-5-1 Node Address, Baud Rate, and Output Hold/Clear
Settings.
5-7-2 Wiring to a Screw-less Clamp Terminal Block
Screw-less Clamp Terminals provide clamp-type terminal blocks that allow
wiring without screws. When connecting a sensor or an external device, a
special post terminal must be attached to the cable for the sensor or device.
Power Supply Wiring Two cables are provided with the DRT2-@D32SL(-1) and DRT2-@D32SLH(-1)
Terminals for V and G, to transfer power between terminal blocks. Use these
cables when there is no need to divide the power by block. The rated current
is 10 A max.
Model Specifications
DRT2-ID16SL(-1) 16 inputs
DRT2-ID32SL(-1) 32 inputs
DRT2-MD32SL(-1) 16 inputs/16 outputs
DRT2-OD16SL(-1) 16 outputs
DRT2-OD32SL(-1) 32 outputs
Model Specifications
DRT2-ID16SLH(-1) 16 inputs
DRT2-ID32SLH(-1) 32 inputs
DRT2-MD32SLH(-1) 16 inputs/16 outputs
DRT2-OD16SLH(-1) 16 outputs
DRT2-OD32SLH(-1) 32 outputs
Manufacturer Model
PHOENIX CONTACT AI-0.5-10
0.5 mm
2
(AWG 20)
AI-0.75-10
0.75 mm
2
(AWG 18)
AI-1.5-10
1.25 mm
2
(AWG 16)
Nihon Weidmuller H 0.5/16 D
0.5 mm
2
(AWG 20)
H 0.75/16 D
0.75 mm
2
(AWG 18)
H 1.5/16 D
1.25 mm
2
(AWG 16)
To Next Page
