Standard Environment-resistive Terminals Section 6-5
6-5-3 Environment-resistive Terminals with 8 Transistor Inputs (IP67):
DRT2-ID08CL (NPN) and DRT2-ID08CL-1 (PNP)
Input Specifications
Indicators
I/O Status Indicators The I/O status indicator displays and their meanings are shown in the follow-
ing table. Refer to the section following on names of components and func-
tions for details on the location of the I/O status indicators. In the indicator
name “1-A,” the “1” indicates the connector number, and the “A” indicates that
it is an I/O status indicator.
Note 1. The I/O status indicator “B” is not used by Units with 8 inputs.
2. Although the connectors are numbered from 1 to 8, the input bits are num-
bered from 0 to 7. (The input bits are also numbered from 0 to 7 in the Con-
figurator display.)
I/O Power Supply Status
Indicator
Item Specifications
Model DRT2-ID08CL DRT2-ID08CL-1
Internal I/O common NPN PNP
Input points 8 points
ON voltage 15 V DC min. (between each
input terminal and V)
15 V DC min. (between each
input terminal and G)
OFF voltage 5 V DC max. (between each
input terminal and V)
5 V DC max. (between each
input terminal and G)
OFF current 1 mA max.
Input current 6.0 mA max./point (for 24 V DC), 3.0 mA min./point (for 17 V
DC)
I/O power supply
voltage
20.4 to 26.4 V DC (24 V DC, −15 to +10%)
ON delay time 1.5 ms max.
OFF delay time 1.5 ms max.
Number of circuits 8 points with one common
Indicator Color Status Meaning
1-A Yellow ON Input 0 is ON.
2-A Yellow ON Input 1 is ON.
3-A Yellow ON Input 2 is ON.
4-A Yellow ON Input 3 is ON.
5-A Yellow ON Input 4 is ON.
6-A Yellow ON Input 5 is ON.
7-A Yellow ON Input 6 is ON.
8-A Yellow ON Input 7 is ON.
Indicator Color Status Meaning
AUX PWR Green ON I/O power is being supplied.
