Common Slave Functions Section 4-2
3. Select the General Tab.
4. Enter the desired value in the Unit Conduction Time field.
5. Click the Download Button, and then click the Reset Button to reset the
Unit.
6. Click the OK Button.
4-2-4 Slave Comments
Function Overview The user can assign and record a name or comment for every Unit (up to 32
characters). The Configurator or explicit messages can be used to read and
write these Unit names (comments).
Setting Using the
DeviceNet
Configurator
The method used to set values from the DeviceNet Configurator (Ver. 2.20 or
later) is described here.
Either of the following two settings methods can be used.
Setting Method 1
1,2,3... 1. Turn ON the power to the DRT2-series Smart Slave.
2. From the Main Window, open the Network Configuration Window and dou-
ble-click or click the right mouse button over the icon of the DRT2-series
Smart Slave to be set. Select Parameter and Edit to display the Edit De-
vice Parameters Window.
From the Maintenance Mode Window, click the right mouse button over the
icon of the DRT2-series Smart Slave to be set. Select Parameter and Edit
to display the Edit Device Parameters Window.
DeviceNet Network
Slave
Unit comment (name)
Recorded in Unit
What is this
Unit used for?
Unit comment
(name)
Configurator
To Next Page
