60
Common Slave Functions Section 4-2
Checking Using the
DeviceNet
Configurator
The method used to check error information from the DeviceNet Configurator
(Ver. 2.20 or later) is described here.
1,2,3... 1. Turn ON the power to the DRT2-series Smart Slave.
2. Click the right mouse button over the icon of the DRT2-series Smart Slave
to be set in the Network Configuration Window, and select Monitor.
3. Select the Error History Tab in the Monitor Device Window. The commu-
nications error history for the last four errors that occurred will be dis-
played, as shown in the following window. To display the most recent error
history, click the Update Button.
Note From the Maintenance Mode Window, double-click the Slave icon, and select
the Error History Tab from the Maintenance Information Window.
4-2-7 Last Maintenance Date
Function Overview This function enables the date on which maintenance was last performed to
be written to the Unit. This means that the timing for future maintenance can
be judged more easily. The date can be written using the Configurator.
To Next Page
