235
Common Specifications for Environment-resistive Slaves Section 6-1
6-1-1 Current Consumption, Weight, Enclosure Ratings
The following table lists the current consumption, weight, and enclosure rat-
ings for Environment-resistive Slaves.
6-1-2 I/O Indicators
Advanced Slaves
(DRT2-@D@@C(-1))
The following table describes the meanings of the I/O indicators provided on
Advanced Environment-resistive Slaves. Two I/O indicators, @-A and @-B, are
provided for each connector.
The box indicates the number of the corresponding connector.
Model Communications
current
consumption
Weight Enclosure rating
DRT2-ID08C 115 mA max. 340 g max. IP67
DRT2-ID08C-1 115 mA max. 340 g max.
DRT2-HD16C 190 mA max. 340 g max.
DRT2-HD16C-1 190 mA max. 340 g max.
DRT2-OD08C 60 mA max. 390 g max.
DRT2-OD08C-1 60 mA max. 390 g max.
DRT2-ID04CL 50 mA max. 275 g max.
DRT2-ID04CL-1 50 mA max. 275 g max.
DRT2-OD04CL 45 mA max. 275 g max.
DRT2-OD04CL-1 45 mA max. 275 g max.
DRT2-ID08CL 50 mA max. 390 g max.
DRT2-ID08CL-1 50 mA max. 390 g max.
DRT2-HD16CL 55 mA max. 390 g max.
DRT2-HD16CL-1 55 mA max. 390 g max.
DRT2-OD08CL 50 mA max. 390 g max.
DRT2-OD08CL-1 50 mA max. 390 g max.
DRT2-WD16CL 55 mA max. 390 g max.
DRT2-WD16CL-1 55 mA max. 390 g max.
DRT2-MD16CL 55 mA max. 390 g max.
DRT2-MD16CL-1 55 mA max. 390 g max.
Indicator Color Status Definition Meaning
@-A Yellow ON Device operational Input ON/Output ON
Red ON Unrecoverable fault Sensor power shorted
Flashing Minor fault Sensor disconnected
--- OFF Device operational Input OFF/output
OFF/input power OFF
@-B Yellow ON Device operational Input ON
Red ON Unrecoverable fault Output load shorted
--- OFF Device operational Input OFF/input power
OFF
