Omron DRT2 SERIES DEVICENET SLAVES - OPERATION MANUAL 04-2008 User Manual

115
Remote I/O Terminals with Transistors Section 5-5
Wiring
DRT2-MD16 (NPN)
DRT2-MD16-1 (PNP)
Note Wire colors in parentheses are the previous JIS colors for photoelectric and
proximity sensors.
V1 1 3 5 7 V2
G1 0 2 4 6 G2
24 V DC
+−
1 3 75 NC
0 2 4 6 NC
+−
I/O power
supply
I/O power
supply
Solenoid valve,
etc.
Solenoid valve,
etc.
3-wire sensor with
NPN output
(photoelectric or
proximity sensor)
2-wire sensor
(e.g., limit switch)
Brown (red) Black (white) Blue (black)
Blue (black)
Brown (white)
V1 1 3 5 7 V2
G1 0 2 4 6 G2
24 V DC
+−
1 3 75
0 2 4 6
NC
NC
+−
I/O power
supply
I/O power
supply
Solenoid valve,
etc.
Solenoid valve,
etc.
3-wire sensor with
PNP output
(photoelectric or
proximity sensor)
2-wire sensor
(e.g., limit switch)
Brown (red) Black (white) Blue (black)
Blue (black)
Brown (white)
