Omron DRT2 SERIES DEVICENET SLAVES - OPERATION MANUAL 04-2008 User Manual

154
Connector Terminals with Transistors Section 5-6
Components of the DRT2-ID16ML(X) and DRT2-ID16ML(X)-1
Input Indicators
Note “m” is the first word allocated to the Remote Input Terminal.
Internal Circuits
DRT2-ID16ML(X) (NPN)
2
Top panel Front panel
Bottom panel
DeviceNet indicators and Input Indicators
Indicate the status of the Slave, communications,
and each input (lit when input is ON).
Rotary switches
Set the node address.
DIN track
mounting hooks
Communications
connector
Input connector (MIL)
Connects the 16 inputs via a MIL connector.
A cable (10 cm) with only an MLX connector
is included.
(×10)
(×1)
T 20
T 20
OMRON
OMRON
XG4
XG4
T 20
T 20
OMRON
OMRON
XG4
XG4
Green
Cable with Connectors (MLX Models Only)
Name Meaning
0 to 15 Indicate the status of bits (contacts) 0 to 15 in word m. Lit
when input is ON; not lit when input is OFF.
V
G
V+
CAN_H
DRAIN
CAN_L
V−
Internal
circuitry
Input
Physical
layer
DC-DC
converter
(non-
isolated)
Input
Photo-
coupler
Photo-
coupler
