Omron DRT2 SERIES DEVICENET SLAVES - OPERATION MANUAL 04-2008 User Manual

185
Connector Terminals with Transistors Section 5-6
Internal Circuits
DRT2-ID32B and DRT2-ID32BV (NPN)
DRT2-ID32B-1 and DRT2-ID32BV-1 (PNP)
V
G
V+
CAN_H
DRAIN
CAN_L
V−
Internal
circuitry
Photo-
coupler
Input
Photo-
coupler
Physical
layer
DC-DC
converter
(non-
isolated)
Input
G
V
V+
CAN_H
DRAIN
CAN_L
V−
Internal
circuitry
Photo-
coupler
Input
Photo-
coupler
Physical
layer
DC-DC
converter
(non-
isolated)
Input
