Screw-less Clamp Terminals Section 5-7
Component Names and Functions (Same for DRT2-ID32SL(-1) and DRT2-ID32SLH(-1))
Internal Circuits
DRT2-ID32SL
MS
NS
I/O
I/O
I/O
I/O
DeviceNet indicators
Rotary Switches (×10, ×1)
Used to set the node address.
Release Button
Releases terminal when
pressed down.
Communications Connector
Input Terminal Block
I/O Power Indicator
Used to check I/O power supply
status.
Input Indicators
Used to check detection results
and input status for each contact.
V+
CAN H
DRAIN
CAN L
V−
V
0-15
G
G
V
V
G
V
0-15
G
G
V
V
G
Physical
layer
DC-DC
converter
Internal circuits
Photo-
coupler
Photo-
coupler
Left side
Right side
