Omron DRT2 SERIES DEVICENET SLAVES - OPERATION MANUAL 04-2008 User Manual

212
Screw-less Clamp Terminals Section 5-7
DRT2-ID32SLH-1
Wiring
DRT2-ID32SL (NPN)
V
0-15
G
V+
CAN H
DRAIN
CAN L
V−
G
V
G
V0-V15
V
0-15
G
G
V
G
V0-V15
Physical
layer
DC-DC
converter
Internal circuits
Photo-
coupler
Photo-
coupler
Left side
Right side
Short-cir-
cuit or dis-
connection
detection
circuit
Short-cir-
cuit or dis-
connection
detection
circuit
15
V
G
1
V
G
0
V
G
V
G
−+
15
V
G
1
V
G
0
V
G
V
G
−+
NC NCNC
V
G
NC
V
G
Blue (black) Brown (white)
2-wire sensor
(e.g., limit switch)
Black (white) Brown (red) Blue (black)
3-wire sensor with NPN output
(photoelectric or proximity sensor)
Blue (black) Brown (white)
2-wire sensor
(e.g., limit switch)
Black (white) Brown (red) Blue (black)
3-wire sensor with NPN output
(photoelectric or proximity sensor)
Left side Right side
