Omron DRT2 SERIES DEVICENET SLAVES - OPERATION MANUAL 04-2008 User Manual

215
Screw-less Clamp Terminals Section 5-7
Component Names and Functions
(Same for DRT2-OD16SL(-1) and DRT2-OD16SLH(-1))
Internal Circuits
DRT2-OD16SL (NPN)
DRT2-OD16SL-1 (PNP)
Rotary Switches
Used to set the node address.
DeviceNet indicators
I/O Power Indicators
Used to check I/O
power supply status.
Output Indicators
Used to check detection results and
output status for each contact.
Communications
Connector
Output Terminal
Block
Releases terminal when pressed down.
Release Button
G
Photo-
coupler
Physi-
cal
layer
DC-DC
converter
Voltage
step-down
V
0 to 1
5
G
G
V
V
Internal circuits
V+
CAN H
DRAIN
CAN L
V−
V
Photo-
coupler
Physi-
cal
layer
DC-DC
converter
Voltage
step-down
G
0 to 1
5
V
V
G
G
Internal circuits
V+
CAN H
DRAIN
CAN L
V−
