232
Screw-less Clamp Terminals Section 5-7
Mounting the End Plates First latch the bottom of the end plate (step 1 in the diagram below), and then
latch the top and pull down (step 2 below).
Note The Slave must be secured on both sides by a pair of end plates.
Mounting Direction Unless specified in the Slave’s documentation, there are no restrictions on the
mounting direction. The Slave can be mounted in any of the six directions
shown below.
1
2
End Plate
