Common Slave Specifications Section 3-1
NS Green Lit Online/connected Network is operating normally (communications
established).
Flashing Online/ not connected Network is operating normally, but communica-
tions have not been established.
Red Lit Critical link failure Communications error (Unit has detected that
network communications are not possible).
Node address duplication
Bus Off error
Flashing Connection time-out Communications time-out.
--- Not lit Not powered/Not online Checking for node address duplication at the
Master.
Switch settings are incorrect.
Power supply is OFF.
