Current Consumption Summary Appendix E
564
Note The communications current consumption indicated for Expansion Units is the additional current con-
sumed when the Expansion Unit is connected to a Basic Unit.
For example, the current consumption for a combination of a DRT2-ID16 Basic Unit and an XWT-OD16
Expansion Unit is 60 + 10 = 70 mA.
Environment-resistive Slaves
DRT2-OD32B 120 mA max.
DRT2-OD32B-1 120 mA max.
DRT2-MD32B 110 mA max.
DRT2-MD32B-1 110 mA max.
DRT2-ID32BV 100 mA max.
DRT2-ID32BV-1 100 mA max.
DRT2-OD32BV 120 mA max.
DRT2-OD32BV-1 120 mA max.
DRT2-MD32BV 110 mA max.
DRT2-MD32BV-1 110 mA max.
DRT2-ID16SL 28 mA max.
DRT2-ID16SL-1 27 mA max.
DRT2-ID32SL 100 mA max.
DRT2-ID32SL-1 90 mA max.
DRT2-OD16SL 32 mA max.
DRT2-OD16SL-1 31 mA max.
DRT2-OD32SL 80 mA max.
DRT2-OD32SL-1 75 mA max.
DRT2-MD32SL 80 mA max.
DRT2-MD32SL-1 80 mA max.
DRT2-ID16SLH 33 mA max.
DRT2-ID16SLH-1 32 mA max.
DRT2-ID32SLH 100 mA max.
DRT2-ID32SLH-1 105 mA max.
DRT2-OD16SLH 35 mA max.
DRT2-OD16SLH-1 35 mA max.
DRT2-OD32SLH 80 mA max.
DRT2-OD32SLH-1 85 mA max.
DRT2-MD32SLH 90 mA max.
DRT2-MD32SLH-1 90 mA max.
Model Communications current
consumption
DRT2-ID08C 115 mA max.
DRT2-ID08C-1 115 mA max.
DRT2-HD16C 190 mA max.
DRT2-HD16C-1 190 mA max.
DRT2-OD08C 60 mA max.
DRT2-OD08C-1 60 mA max.
DRT2-ID04CL 50 mA max.
DRT2-ID04CL-1 50 mA max.
DRT2-ID08CL 50 mA max.
Model Communications current
consumption
