In
Quick
Programming
Mode,
the
parameters
required
for
Inverter
trial
operation
can
be
monitored
and
set.
Parameters
can
be
changed
from
the
setting
displays.
Use
the
Increment,
Decrement,
and
Digit
Selection/
RESET
Keys
to
change
the
frequency.
The
parameter
will
be
written
and
the
monitor
display
will
be
returned
to
when
the
ENTER
Key
is
pressed
after
changing
the
setting.
Refer
to
Chapter
5
Parameters
for
details
on
the
parameters
displayed
in
Quick
Programming
Mode.
nExample
Operations
Key
operations
in
Quick
Programming
Mode
are
shown
in
the
following
figure.
Fig 3.5 Operations in Quick Programming Mode (Example for the 3G3IV-PJVOP161)
Quick Programming Mode
DRIVE QUICK
VERIFY
ADV
Mode Selection Display
MENU
Monitor Display Setting Display
Control method selection
Reference selection
Operation method selection
Stopping method selection
Motor protection selection
Deceleration stall selection
AO CH2 output gain
AO CH1 output gain
C1-01: Acceleration time 1
C1-02: Deceleration time 1
C6-01: CT/VT selection
C6-02: Carrier frequency
selection
d1-01: Frequency reference 1
d1-02: Frequency reference 2
d1-03: Frequency reference 3
d1-04: Frequency reference 4
d1-17: Jog frequency reference
E1-01: Input voltage setting
E1-03: V/f pattern selection
E1-04: Max. output frequency
E1-05: Max. voltage
E1-06: Base frequency
E1-09: Min. output frequency
E1-13: Base voltage (VBASE)
E2-01: Motor rated current
DRIVE QUICK
VERIFY
ADV
ESC
ESC
ESC
ESC
ESC
ESC
ESC
ESC
ESC
ESC
ESC
ESC
ESC
ESC
ESC
AUTO
TUNING
AUTO
TUNING
To Next Page
