Application and Overload Selections
K
KK
K Select the Overload to Suit the Application
Set C6-01 (CT: Low carrier constant torque, VT: High carrier variable torque) depending on the application
for which the Inverter is used. The setting ranges for the Inverter carrier frequency, overload tolerance, and
maximum output frequency depend on the setting in C6-01. If using the Inverter with C6-01 set to the factory
setting (1: VT), use a load application in which load torque reduces with the speed, e.g., fans and pumps.
nRelated Parameters
*1.The factory settings depend on the Inverter capacity.
*2.The setting ranges depend on the Inverter capacity.
*3.Can be set and referenced only when C6-01 is set to 1, and C6-02 is set to F.
Param-
eter
Num-
ber
Name
Description
Setting
Range
Factory
Setting
Change
s during
Opera-
tion
Control Methods
LCD Display V/f
V/f
with
PG
Open
Loop
vec-
tor
C6-01
CT/VT selection
0: CT (low carrier, constant torque, 150% per
minute)
1: VT (high carrier, variable torque, 120% per
minute)
0 or 11 NoQQQ
Heavy/Normal Duty
C6-02
Carrier frequency selection
Select carrier wave fixed pattern.
Select F to enable detailed settings using parame-
ters C6-03 to C6-05.
0 to F
6*1
No Q Q Q
CarrierFreq Sel
C6-03
Carrier frequency upper
limit
Set upper and lower carrier frequency limits in
kHz.
Set the carrier wave gain as shown below.
In vector control method, the carrier frequency is
fixed according to C6-03 (Carrier Frequency
Upper Limit).
K is the coefficient determined by the set value in
C6-03.
C6-03 ≥ 10.0 kHz: K = 3
10.0 kHz > C6-03 ≥ 5.0 kHz
: K = 2
5.0 kHz > C6-03: K = 2
2.0 to
15.0
*2 *3
15.0 kHz
*1
No A A A
CarrierFreq Max
C6-04
Carrier frequency lower
limit
0.4 to
15.0
*2 *3
15.0 kHz
*1
No A A No
CarrierFreq Min
C6-05
Carrier frequency
proportional gain
00 to 99
*3
00 No A A No
CarrierFreq Gain
C
arrier frequency
Output frequency x
(C6-05) x K
Output frequency
(Maximum output frequency)
