Omron SYSDRIVE 3G3RV Series

9
-
8
K
KK
K Special Mounted Options
The special mounted options are described in this section.
n Fan Unit
Replacement fan for Inverters equipped with a cooling fan.
Replace the Cooling Fan when the fan replacement time has come or a cooling fan fault (FAN) alarm has been
displayed.
Models and Application
The standard models of Fan Units are listed in the following table.
Refer to Chapter 8 Maintenance and Inspection for the Fan Unit replacement procedure.
Inverter Replacement Cooling Fan
Voltage
Class
Max. Applicable
Motor Capacity
(kW)
Model No. Model No. Qty Used
3-phase, 200
VA C
0.4 3G3RV-A2004
No Fan -
0.75 3G3RV-A2007
1.5 3G3RV-A2015
2.2 3G3RV-A2022
3.7 3G3RV-A2037
3G3IV-PFAN001041
1
5.5 3G3RV-A2055
7.5 3G3RV-A2075
2
11 3G3RV-A2110
15 3G3RV-A2150
3G3IV-PFAN001042 2
18.5 3G3RV-A2185
22 3G3RV-B2220
3G3IV-PFAN001039 2
30 3G3RV-B2300
37 3G3RV-B2370
3G3IV-PFAN001049 2
45 3G3RV-B2450
55 3G3RV-B2550
3G3IV-PFAN001052 2
75 3G3RV-B2750
90 3G3RV-B2900
3G3IV-PFAN000111 2
110 3G3RV-B211K
3-phase, 400
VA C
0.4 3G3RV-A4004
No Fan -0.75 3G3RV-A4007
1.5 3G3RV-A4015
2.2 3G3RV-A4022
3G3IV-PFAN001041 13.7 3G3RV-A4037
5.5 3G3RV-A4055
7.5 3G3RV-A4075
3G3IV-PFAN001042 2
11 3G3RV-A4110
15 3G3RV-A4150
18.5 3G3RV-A4185
22 3G3RV-B4220
3G3IV-PFAN001039 2
30 3G3RV-B4300
37 3G3RV-B4370
3G3IV-PFAN001044 245 3G3RV-B4450
55 3G3RV-B4550
75 3G3RV-B4750
3G3IV-PFAN001052 2
90 3G3RV-B4900
110 3G3RV-B411K
3G3IV-PFAN000111 2132 3G3RV-B413K
160 3G3RV-B416K
