6
-
32
Speed
Limit
(Frequency
Reference
Limit
Func-
tion)
This
section
explains
how
to
limit
the
motor
speed.
K
KK
K Limiting
Maximum
Output
Frequency
If
you
do
not
want
the
motor
to
rotate
above
a
given
frequency,
use
parameter
d2-01.
Set
the
upper
limit
value
of
the
Inverter
output
frequency
as
a
percent,
taking
E1-04
(Maximum
Output
Fre-
quency)
to
be
100%.
nRelated
Parameters
K
KK
K Limiting
Minimum
Frequency
If
you
do
not
want
the
motor
to
rotate
at
below
a
given
frequency,
use
parameters
d2-02
or
d2-03.
There
are
two
methods
of
limiting
the
minimum
frequency,
as
follows:
• Adjust
the
minimum
level
for
all
frequencies.
• Adjust
the
minimum
level
for
the
master
speed
frequency
(i.e.,
the
lower
levels
of
the
jog
frequency,
multi-
step
speed
frequency,
and
auxiliary
frequency
will
not
be
adjusted).
nRelated
Parameters
Param-
eter
Num-
ber
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control
Methods
V/f
V/f
with
PG
Open
Loop
Vec-
tor
LCD
Display
d2-01
Frequency
reference
upper
limit
Set
the
output
frequency
upper
limit
as
a
percent,
taking
the
max.
output
frequency
to
be
100%.
0.0
to
110.0
100.0% No A A A
Ref
Upper
Limit
Param-
eter
Num-
ber
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control
Methods
V/f
V/f
with
PG
Open
Loop
Vec-
tor
LCD
Display
d2-02
Frequency
reference
lower
limit
Set
the
output
frequency
lower
limit
as
a
percent,
taking
the
base
reference
to
be
100%.
0.0
to
110.0
0.0% No A A A
Ref
Lower
Limit
d2-03
Master
speed
reference
lower
limit
Set
the
master
speed
reference
lower
limit
as
a
percent,
taking
the
max.
output
frequency
to
be
100%.
0.0
to
110.0
0.0% No A A A
Ref1
Lower
Limit
