Omron SYSDRIVE 3G3RV Series User Manual

P
arameter Tables
5
-
6
9
nHigh-slip Braking: N3
Parameters for high-slip braking are shown in the following table.
K
KK
K Digital Operator Parameters: o
The following settings are made with the Digital Operator parameters (o parameters): Multi-function selec-
tions and the copy function.
nMonitor Select: o1
Parameters for Digital Operator Displays are shown in the following table.
Param-
eter
Number
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control
Methods
Register Page
LCD
Display
V/f
V/f
with
PG
N3-01
High-slip
braking
decelera-
tion fre-
quency
width
Sets the frequency width for
deceleration during high-slip
braking as a percent, taking the
Maximum Frequency (E1-04) as
100%.
1 to 20 5% No A A 588H -
HSB Decel
Width
N3-02
High-slip
braking cur-
rent limit
Sets the current limit for decelera-
tion during high-slip braking as a
percent, taking the motor rated
current as 100%. The resulting
limit must be 150% of the Inverter
rated current or less.
100 to
200
150% No A A 589H -
HSB Cur-
rent Ref
N3-03
High-slip
braking stop
dwell time
Set in seconds the dwell time for
the output frequency for FMIN
(1.5 Hz) during V/f control.
Effective only during deceleration
for high-slip braking.
0.1 to
10.0
1.0 s No A A 58AH -
HSB Dwel-
Tim@Stp
N3-04
High-slip
braking OL
time
Set the OL time when the output
frequency does not change for
some reason during deceleration
for high-slip braking.
30 to
1200
40 s No A A 58BH -
HSB OL
Time
Param-
eter
Number
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
Register Page
LCD
Display
V/f
V/f
with
PG
Open
Loop
o1-01
Monitor
selection
Set the number of monitor
item. (U1-oo)
It is displayed on the digital
operator in 4th item in Drive
mode. The factory setting
(Output voltage monitor) can
be changed.
4 to 406 YesAAA500H -
User Moni-
tor Sel
