Fig 6.29 Frequency Bias Adjustment (Terminal A2 Input)
For example, if H3-02 is 100%, H3-03 is 0%, and terminal A2 is set to 1 V, the frequency reference from
terminal A1 when 0 V is input to A1 will be 10%.
K
KK
K Operation Avoiding Resonance (Jump Frequency Function)
The jump frequency function operates the motor while avoiding resonance caused by characteristic frequen-
cies in the machinery.
This function is effective in creating a frequency reference dead band.
During constant-speed operation, operation within the jump frequency range is prohibited. Smooth operation
still used during acceleration and deceleration, i.e., jumps are not performed.
nRelated Parameters
Param-
eter
Num-
ber
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
V/f
V/f
with
PG
Open
Loop
Vec-
tor
LCD Display
d3-01
Jump frequency 1
Set the frequency center value at which to prohibit
settings, in hertz.
Set to 0.0 to disable the jump frequency.
Make sure the settings are as follows: d3-01 ≥ d3-
02 ≥ d3-03.
Operation within the jump frequency range is pro-
hibited. Changes during acceleration and decelera-
tion are made gradually without performing
jumps.
0.0 to
400.0
0.0 Hz No A A A
Jump Freq 1
d3-02
Jump frequency 2
0.0 Hz No A A A
Jump Freq 2
d3-03
Jump frequency 3
0.0 Hz No A A A
Jump Freq 3
d3-04
Jump frequency width Set the jump frequency width in hertz.
The jump frequency range is as follows: (Jump
frequency ±d3-04).
0.0 to
20.0
1.0 Hz No A A A
Jump Bandwidth
Frequency bias
Multi-function analog input
terminal A2 input level
Terminal A1 input voltage
Frequency reference
H3-02
10%
Bias
0 V 10 V
