K Verify Mode
Verify Mode is used to display any parameters that have been changed from their default settings in a Pro-
gramming Mode or by autotuning. “None” will be displayed if no settings have been changed.
Of the Environment Mode settings, only A1-02 will be displayed if it has been changed. Other Environment
Modes settings will not be displayed even if they have been changed from their default settings.
Even in Ve ri f y Mode, the same procedures can be used to change settings as are used in the Programming
Modes. Use the Increment, Decrement, and Digit Selection/RESET Keys to change the frequency. The param-
eter will be written and the monitor display will be returned to when the ENTER Key is pressed after changing
the setting.
nExample Operations
An example of key operations is given below for when the following settings have been changed from their
default settings: b1-01 (Reference Selection), C1-01 (Acceleration Time 1), E1-01 (Input Vo lt a ge Setting), and
E2-01 (Motor Rated Current).
Fig 3.7 Operations in Verify Mode (Example for the 3G3IV-PJVOP161)
DRIVE QUICK
VERIFY
ADV
DRIVE QUICK
VERIFY
ADV
Monitor Display
MENU
Setting Display
Verify Mode
Mode Selection Display
Acceleration time 1
Input voltage setting
Motor rated current
DRIVE QUICK
VERIFY
ADV
ESC
ESC
ESC
ESC
ESC
ESC
ESC
ESC
Acceleration time 1
Input voltage setting
Motor rated current
Frequency reference
selection
Frequency reference
selection
AUTO
TUNING
AUTO
TUNING
AUTO
TUNING
