Inverter Protection
This section explains the functions for protecting the Inverter and the braking resistor.
K
KK
K Performing Overheating Protection on Mounted Braking Resistors
Perform overheating protection on Inverter-mounted braking resistors (3G3IV-PERFo).
When overheating in a mounted braking resistor is detected, an alarm RH (Mounted braking resistor overheat-
ing) is displayed on the Digital Operator, and the motor coasts to a stop.
nRelated Parameters
Multi-function Digital Outputs (H2-01 to H2-03)
Param-
eter
Num-
ber
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
V/f
V/f
with
PG
Open
Loop
Vec-
tor
LCD Display
L8-01
Protect selection for inter-
nal DB resistor
0: Disabled (no overheating protection)
1: Enabled (overheating protection)
0 or 10 NoAAA
DB Resistor Prot
Set Value Details
Control Methods
V/f
V/f
with
PG
Open
Loop
Vec-
tor
DBraking resistor fault (ON: Resistor overheats or brake transistor f au lt) Yes Yes Ye s
INFO
The most likely causes of RH (Mounted braking resistor overheating) being detected are that the deceleration
time is too short or that the motor regeneration energy is too large. In these cases, lengthen the deceleration
time or replace the Braking Resistor Unit with one with a higher breaking capacity.
