Installation Orientation and Space
!WARNING Provide an appropriate stopping device on the machine side to secure safety. (A hold-
ing brake is not a stopping device for securing safety.) Not doing so may result in
injury.
!WARNING Provide an external emergency stopping device that allows an instantaneous stop of
operation and power interruption. Not doing so may result in injury.
!Caution Be sure to install the product in the correct direction and provide specified clearances
between the Inverter and control panel or with other devices. Not doing so may result
in fire or malfunction.
!Caution Do not allow foreign objects to enter inside the product. Doing so may result in fire or
malfunction.
!Caution Do not apply any strong impact. Doing so may result in damage to the product or mal-
function.
K
KK
K Inverter Installation Orientation and Space
Install the Inverter vertically so as not to reduce the cooling effect. When installing the Inverter, always
provide the following installation space to allow normal heat dissipation.
Fig 1.11 Inverter Installation Orientation and Space
50 mm min.
50 mm min.
30 mm min.
30 mm min.
120 mm min.
120 mm min.
Air
Air
Vertical SpaceHorizontal Space
