n Simple Input Noise Filter
A
Simple
Input
Noise
Filter
reduces
noise
coming
into
the
inverter
from
the
power
supply
line
and
to
reduce
noise
flowing
from
the
inverter
into
the
power
supply
line.
Connected
the
Filter
to
the
power
supply
input
side.
Models and Application
The
standard
models
of
Simple
Input
Noise
Filters
listed
in
the
following
table.
Inverter Simple Input Noise Filter
Voltage
Class
Max. Applicable
Motor Capacity
(kW)
Model No. Qty
Rated
Current
(A)
200-V
Class
0.4 3G3EV-PLNFD2103DY 1 10
0.75 3G3EV-PLNFD2103DY 1 10
1.5 3G3EV-PLNFD2103DY 1 10
2.2 3G3EV-PLNFD2153DY 1 15
3.7 3G3EV-PLNFD2303DY 1 30
5.5 3G3EV-PLNFD2203DY 2 40
7.5 3G3EV-PLNFD2303DY 2 60
11 3G3EV-PLNFD2303DY 3 90
15 3G3EV-PLNFD2303DY 3 90
18.5 3G3EV-PLNFD2303DY 4 120
22 3G3EV-PLNFD2303DY 4 120
400-V
Class
0.4 3G3EV-PLNFD4053DY 1 5
0.75 3G3EV-PLNFD4053DY 1 5
1.5 3G3EV-PLNFD4103DY 1 10
2.2 3G3EV-PLNFD4103DY 1 10
3.7 3G3EV-PLNFD4153DY 1 15
5.5 3G3EV-PLNFD4203DY 1 20
7.5 3G3EV-PLNFD4303DY 1 30
11 3G3EV-PLNFD4203DY 2 40
15 3G3EV-PLNFD4303DY 2 60
18.5 3G3EV-PLNFD4303DY 2 60
22 3G3EV-PLNFD4303DY 3 90
30 3G3EV-PLNFD4303DY 3 90
37 3G3EV-PLNFD4303DY 4 120
45 3G3EV-PLNFD4303DY 4 120
