Installing and Wiring Option Cards
K
KK
K Option Card Models and Specifications
Up to three Option Cards can be mounted in the Inverter. You can mount up one Card into each of the three
places on the controller card (A, C, and D) shown in Fig 2.34.
Table 2.24 lists the type of Option Cards and their specifications.
*An Option Card in Mounting Location D is supported by Asian Models only. Other models do not have the CN3 connector shown in Fig 2.34.
K
KK
K Installation
Before mounting an Option Card, remove the terminal cover and be sure that the charge indicator inside the
Inverter is not lit. After confirming that the charge indicator is not lit, remove the Digital Operator and front
cover and then mount the Option Card.
Refer to documentation provided with the Option Card for actual mounting instructions for option slots A, C,
and D.
Table 2.24 Option Card Specifications
Card Model Specifications
Mounting
Location
PG Speed Control Cards
3G3FV-PPGA2 Serial open-collector/complimentary inputs A
3G3FV-PPGB2 Phase A/B complimentary inputs A
3G3FV-PPGD2 Single line-driver inputs A
3G3FV-PPGX2 Phase A/B line-driver inputs A
DeviceNet Communications
Card
3G3FV-PDRT1-SIN DeviceNet communications support C
Analog Monitor Card
3G3FV-PA008 8-bit analog outputs, 2 channels D
3G3FV-PA012 12-bit analog outputs, 2 channels D
