K Factory Settings that Change with the Inverter Capacity (o2-04)
The factory settings of the following parameters will change if the Inverter capacity (o2-04) is changed.
n200-V Class Inverters
Parame-
ter
Num-
ber
Name Unit Factory Setting
- Inverter Capacity kW 0.4 0.75 1.5 2.2 3.7 5.5 7.5 11 15
o2-04 kVA selection - 0 1 2 3 4 5 6 7 8
b8-03
Energy-saving filter time
constant
s0.50 (Open loop vector control)
b8-04
Energy-saving coeffi-
cient
-
288.20 223.70 169.40 156.80 122.90 94.75 72.69 70.44 63.13
C6-02
Carrier frequency selec-
tion
*
-666666666
-
Carrier frequency selec-
tion upper limit
-666666666
E2-01
(E4-01)
Motor rated current A 1.90 3.30 6.20 8.50 14.00 19.60 26.60 39.7 53.0
E2-02
(E4-02)
Motor rated slip Hz 2.90 2.50 2.60 2.90 2.73 1.50 1.30 1.70 1.60
E2-03
(E4-03)
Motor no-load current A 1.20 1.80 2.80 3.00 4.50 5.10 8.00 11.2 15.2
E2-05
(E4-05)
Motor line-to-line resis-
tance
Ω
9.842 5.156 1.997 1.601 0.771 0.399 0.288 0.230 0.138
E2-06
(E4-06)
Motor leak inductance % 18.2 13.8 18.5 18.4 19.6 18.2 15.5 19.5 17.2
E2-10
Motor iron loss for
torque compensation
W 14 26 53 77 112 172 262 245 272
L2-02
Momentary power loss
ridethru time
s0.10.10.20.30.51.01.01.02.0
L2-03
Min. baseblock (BB)
time
s0.10.20.30.40.50.60.70.80.9
L2-04 Voltage recovery time s0.30.30.30.30.30.30.30.30.3
L8-02 Overheat pre-alarm level °C 95 95 95 100 95 95 95 95 90
