Omron SYSDRIVE 3G3RV Series User Manual

6
-
74
10 V/100% monitor output × output gain + output bias
Fig 6.53 Monitor Output Adjustment
nSwitching Analog Monitor Signal Levels
Monitor items corresponding to 0 to ±10 V output 0 to 10 V signals when the monitor value is positive (+),
and 0 to -10 V signals when the monitor value is negative (-). For monitor items corresponding to 0 to ±10 V,
refer to Chapter 5 Parameters.
K
KK
K Using Pulse Train Monitor Parameters
This section explains pulse monitor parameters.
nRelated Parameters
nSelecting Pulse Monitor Items
Output digital operator monitor items (U1-oo [status monitor]) from pulse monitor terminal MP-SC. Refer to
Chapter 5 Parameters, and set the
oo part of U1-oo (Status monitor). The possible monitor selections are
limited as follows: U1-01, 02, 05, 20, 24, 36.
INFO
You can select the signal levels separately for multi-function analog output terminals and analog output option
terminals.
Param-
eter
Num-
ber
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
V/f
V/f
with
PG
Open
Loop
Vec-
tor
LCD Display
H6-06
Pulse train monitor selec-
tion
Select the pulse train monitor output items (value
of the oo part of U1-oo).
There are two types of monitor items: Speed-
related items and PID-related items.
1, 2, 5,
20, 24, 36
2YesAAA
Pulse Moni Sel
H6-07
Pulse train monitor scaling Set the number of pulses output when speed is
100% in hertz.
Set H6-06 to 2, and H6-07 to 0, to make the pulse
train monitor output synchronously to the output
frequency.
0 to
32000
1440 Hz Yes A A A
Pulse Moni Scale
Output voltage
Gain x 10 V
Bias x 10/100 V
Monitor item
