Omron SYSDRIVE 3G3RV Series User Manual

P
arameter Tables
5
-
1
9
K
KK
K Tuning Parameters: C
The following settings are made with the tuning parameters (C parameters): Acceleration/deceleration times,
s-curve characteristics, slip compensation, torque compensation, speed control, and carrier frequency func-
tions.
nAcceleration/Deceleration: C1
Parameters for acceleration and deceleration times are shown in the following table.
Param-
eter
Number
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
Register Page
LCD
Display
V/f
V/f
with
PG
Open
Loop
C1-01
Accelera-
tion time 1
Sets the acceleration time to
accelerate from 0 to the max-
imum output frequency, in 1-
second units.
0.0 to
6000.0
*
10.0 s
YesQQQ200H
4-7
6-19
Accel Time
1
C1-02
Decelera-
tion time 1
Sets the deceleration time to
decelerate from the maxi-
mum output frequency to 0,
in 1-second units.
YesQQQ201H
4-7
6-19
Decel Time
1
C1-03
Accelera-
tion time 2
The acceleration time when
the multi-function input
“accel/decel time 1” is set to
ON.
Yes A A A 202H 6-19
Accel Time
2
C1-04
Decelera-
tion time 2
The deceleration time when
the multi-function input
“accel/decel time 1” is set to
ON.
Yes A A A 203H 6-19
Decel Time
2
C1-05
Accelera-
tion time 3
The acceleration time when
the multi-function input
“accel/decel time 2” is set to
ON.
No A A A 204H 6-19
Accel Time
3
C1-06
Decelera-
tion time 3
The deceleration time when
the multi-function input
“accel/decel time 2” is set to
ON.
No A A A 205H 6-19
Decel Time
3
C1-07
Accelera-
tion time 4
The acceleration time when
the multi-function input
“accel/decel time 1” and
“accel/decel time 2” are set
to ON.
No A A A 206H 6-19
Accel Time
4
C1-08
Decelera-
tion time 4
The deceleration time when
the multi-function input
“accel/decel time 1” and
“accel/decel time 2” are set
to ON.
No A A A 207H 6-19
Decel Time
4
