T
rial Operation Procedures
4
-
7
K
KK
K Basic
Settings
Switch
to
the
quick
programming
mode
(the
QUICK
indicator
on
the
Digital
Operation
should
be
lit)
and
then
set
the
following
parameters.
Refer
to
Chapter
3
Digital
Operator
and
Modes
for
Digital
Operator
operating
procedures
and
to
Chapter
5
Parameters
and
Chapter
6
Parameter
Settings
by
Function
for
details
on
the
parameters.
Parameters
that
must
be
set
are
listed
in
Table
4.2
and
those
that
are
set
according
to
the
application
are
listed
in
Table
4.3.
Table 4.2 Parameters that must be set
Parame-
ter Num-
ber
Name Description Setting Range
Factory
Setting
Page
A1-02
Control
method
selection
Set
the
control
method
for
the
Inverter.
0:
V/f
control
1:
V/f
control
with
PG
(Pulse
generator
as
encoder)
2:
Open-loop
vector
control
0
to
205-9
b1-01 Reference
selection
Set
the
frequency
reference
input
method.
0:
Digital
Operator
1:
Control
circuit
terminal
(analog
input)
2:
RS-422A/485
communications
3:
Option
Card
4:
Pulse
train
input
0
to
41
5-11
6-6
6-62
6-76
b1-02
Operation
method
selection
Set
the
run
command
input
method.
0:
Digital
Operator
1:
Control
circuit
terminal
(sequence
input)
2:
RS-422A/485
communications
3:
Option
Card
0
to
31
5-12
6-12
6-62
6-76
C1-01 Acceleration
time
1
Set
the
acceleration
time
in
seconds
for
the
output
frequency
to
climb
from
0%
to
100%.
0.0
to
6000.0 10.0
s
5-19
6-19
C1-02 Deceleration
time
1
Set
the
deceleration
time
in
seconds
for
the
output
frequency
to
fall
from
100%
to
0%.
0.0
to
6000.0 10.0
s
5-19
6-19
C6-01 CT/VT
selection
Set
to
CT
(not
low
noise,
maximum
current
overload:
150%)
or
VT
(low
noise,
maxi-
mum
current
overload:120%).
0:
CT
1:
VT
0
or
11
5-25
6-2
E1-01
Input
voltage
set-
ting
Set
the
Inverter's
nominal
input
voltage
in
volts.
155
to
255
V
(200
V
class)
310
to
510
V
(400
V
class)
200
V
(200
V
class)
400
V
(400
V
class)
5-31
6-129
E2-01 Motor
rated
current Set
the
motor
rated
current.
10%
to
200%
of
Inverter's
rated
current
Setting
for
general-
purpose
motor
of
same
capacity
as
Inverter
5-33
6-47
6-127
