K Protection Function Parameters: L
The following settings are made with the protection function parameters (L parameters): Motor selection func-
tion, power loss ridethrough function, stall prevention function, frequency detection, torque limits, and hard-
ware protection.
nMotor Overload: L1
Parameters for motor overloads are shown in the following table.
Param-
eter
Number
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
Register Page
LCD
Display
V/f
V/f
with
PG
Open
Loop
L1-01
Motor pro-
tection
selection
Sets whether the motor over-
load function is enabled or
disabled at electric thermal
overload relay.
0: Disabled
1: General-purpose motor
protection
2: Inverter motor protection
3: Vector motor protection
In some applications when
the Inverter power supply is
turned off, the thermal value
is reset, so even if this
parameter is set to 1,
protection may not be
effective.
When several motors are
connected to one Inverter,
set to 0 and ensure that each
motor is installed with a pro-
tection device.
0 to 3 1 No Q Q Q 480H
4-8
6-47
MOL Fault
Select
L1-02
Motor pro-
tection time
constant
Sets the electric thermal
detection time in seconds.
Usually setting is not neces-
sary.
The factory setting is 150%
overload for one minute.
When the motor's overload
resistance is known, also set
the overload resistance pro-
tection time for when the
motor is hot started.
0.1 to
5.0
(0.1 to
20.0)
1.0 min
(8.0
min)
No A A A 481H 6-47
MOL Time
Const
